The product of this model is a LED VOLTAGE REGULATOR design of LED digital display .It is characterized by stable work, high pressure regulation speed and wide voltage regulation range. APPLICATION
COC
Hinorms PITBULL UKN HN
Availability: | |
---|---|
Quantity: | |
PRODUCT FEATURES
TMH45 power stabilizer for home This series is designed for home and office users.It is not big or heavy and can be changed at will.Its minimum input voltage can even reach 45V, at which point, it is far more than many other manufacturers in the industry.Inside the fittings and wiring harnesses, we employ high specification and standard selection.
Product advantages:
We have designed it multiple protection, in all kinds of overvoltage, undervoltage, short circuit, overload and other cases, can automatically cut off, in order to protect our electrical appliances and regulators from being damaged.And it has a very wide input range.It can make electrical appliances work normally over a wide range of areas.
Application scenario:
TMH45 2021 regulators are mainly used in home and office environments.It can be connected to some computers, air conditioners, refrigerators, ovens and other household equipment and office equipment.Its relatively lightweight size allows it to be placed anywhere the user wants.
Design concept:
TMH45 power stabilizer for home's design color scheme can be matched according to customer requirements.We have a complete design team.Can help clients realize their design concepts.
PRODUCT FEATURES
TMH45 power stabilizer for home This series is designed for home and office users.It is not big or heavy and can be changed at will.Its minimum input voltage can even reach 45V, at which point, it is far more than many other manufacturers in the industry.Inside the fittings and wiring harnesses, we employ high specification and standard selection.
Product advantages:
We have designed it multiple protection, in all kinds of overvoltage, undervoltage, short circuit, overload and other cases, can automatically cut off, in order to protect our electrical appliances and regulators from being damaged.And it has a very wide input range.It can make electrical appliances work normally over a wide range of areas.
Application scenario:
TMH45 2021 regulators are mainly used in home and office environments.It can be connected to some computers, air conditioners, refrigerators, ovens and other household equipment and office equipment.Its relatively lightweight size allows it to be placed anywhere the user wants.
Design concept:
TMH45 power stabilizer for home's design color scheme can be matched according to customer requirements.We have a complete design team.Can help clients realize their design concepts.
MODEL | COC(500VA-20kVA) | ||
INPUT VOLTAGE | AC 45V-280V | ||
OUTPUT VOITAGE | AC 220V±10% 50/60Hz | ||
DELAY TIME | Short Delay:3-5sec Long Delay:3-7min | ||
PROTECTION | Over Voltage(246V±4V),Overload,High Temperature,Short Circuit | ||
POWER | 500VA-20kVA | ||
FEATURE | The product of this model is a 220V fully automatic voltage regulator, both for desktop and wall mounted .With concise and generous design,multiple screen optional.it is characterized by stable work, high pressure regulation speed and wide voltage | ||
APPLICATION | It is Widely used in various industries, small office equipment and refrigerators, electric fans, air conditioning, television and other small appliances. | ||
Power Factor | ≥0.9 | ||
Control | 5-7 relays | ||
Digital display | show input and output voltage、Over\Low Voltage、Overload、delay、temperature | show input and output voltage、Over\Low Voltage、Overload、delay、temperature | show input and output voltage、Over\Low Voltage、Overload、delay、temperature |
Temperature protection | yes | yes | yes |
Short circuit&over load | air-switch/(fuse:500-2000va) | air-switch/(fuse:500-2000va) | air-switch/(fuse:500-2000va) |
Cooling type | FAN/Vents | FAN/Vents | FAN/Vents |
Efficiency | AC 97% | AC 97% | AC 97% |
Temperature | .-20°~55℃ | .-20°~55℃ | .-20°~55℃ |
Humidity | <90 | <90 | <90 |
MODEL | COC(500VA-20kVA) | ||
INPUT VOLTAGE | AC 45V-280V | ||
OUTPUT VOITAGE | AC 220V±10% 50/60Hz | ||
DELAY TIME | Short Delay:3-5sec Long Delay:3-7min | ||
PROTECTION | Over Voltage(246V±4V),Overload,High Temperature,Short Circuit | ||
POWER | 500VA-20kVA | ||
FEATURE | The product of this model is a 220V fully automatic voltage regulator, both for desktop and wall mounted .With concise and generous design,multiple screen optional.it is characterized by stable work, high pressure regulation speed and wide voltage | ||
APPLICATION | It is Widely used in various industries, small office equipment and refrigerators, electric fans, air conditioning, television and other small appliances. | ||
Power Factor | ≥0.9 | ||
Control | 5-7 relays | ||
Digital display | show input and output voltage、Over\Low Voltage、Overload、delay、temperature | show input and output voltage、Over\Low Voltage、Overload、delay、temperature | show input and output voltage、Over\Low Voltage、Overload、delay、temperature |
Temperature protection | yes | yes | yes |
Short circuit&over load | air-switch/(fuse:500-2000va) | air-switch/(fuse:500-2000va) | air-switch/(fuse:500-2000va) |
Cooling type | FAN/Vents | FAN/Vents | FAN/Vents |
Efficiency | AC 97% | AC 97% | AC 97% |
Temperature | .-20°~55℃ | .-20°~55℃ | .-20°~55℃ |
Humidity | <90 | <90 | <90 |
