PRODUCT FEATURES

The product of this model is a high-precision 220v voltage regulator both for desktop and wall mounted,with LED digital display design, using motor-driven carbon brush sliding between turns of self-coupling transformer winding and directly adjust the output voltage, two kinds of output voltage 110V/220V.

This unit of high-precision and 220v voltage regulator was designed and produced by adopting automatic regulating principles,accepted internationally. Its primary parts and devices are all imported ones, which features high precision stabilization, minimal output wave distortion,small power consumption, compact size and lightweight. It can be widely applied in computer lab,experiment lab and factories,and it's ideal in providing stabilized voltage for high-class electrical appliance. Compared with other AC stabilizers, the 220v voltage regulator has a better performance price ratio.

MODEL	COC(500VA-2kVA)
INPUT VOLTAGE	AC 95V-270V
OUTPUT VOITAGE	AC 220V±10% 50/60Hz
DELAY TIME	Short Delay:3-5sec Long Delay:3-7min
PROTECTION	Over Voltage(246V±4V),Overload,High Temperature,Short Circuit
POWER	500VA-2kVA
FEATURE	The product of this model is a 220V fully automatic voltage regulator, both for desktop and wall mounted .With concise and generous design,multiple screen optional.it is characterized by stable work, high pressure regulation speed and wide voltage regulation range.
APPLICATION	It is Widely used in various industries, small office equipment and refrigerators, electric fans, air conditioning, television and other small appliances.
Power Factor	≥0.9
Control	5 relays
Digital display	show input and output voltage、Over\Low Voltage、Overload、delay、temperature	show input and output voltage、Over\Low Voltage、Overload、delay、temperature	show input and output voltage、Over\Low Voltage、Overload、delay、temperature
Temperature protection	yes	yes	yes
Short circuit&over load	air-switch/（fuse：500-2000va）	air-switch/（fuse：500-2000va）	air-switch/（fuse：500-2000va）
Cooling type	FAN/Vents	FAN/Vents	FAN/Vents
Efficiency	AC 97%	AC 97%	AC 97%
Temperature	.-20°~55℃	.-20°~55℃	.-20°~55℃
Humidity	<90	<90	<90

R-image2 R-image3 R-image4 R-image5 R-image6

Q 1. How reliable is your control system?

A. We use syhn20E95 and syhn20E45 control module in our relay type stabilizers，which is independently developed by ourself. The program is stable and safe, and it is completely waterproof and sealed.

Q 2. how's the delivery time ?

A. usually it will take about two weeks for production.

Q 3. tell me the standard of package?

A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection.

Q 4. Could you offer Form A or C/O ?

A. It totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for this certificate.

Q 5.Would you accept to use our logo ?

A.If you have good quantity,it absolute no problem to do OEM or ODM.

Q 6.We want to know month capacity.

A. It depends on which model.For example for relay type small capacity , month capacity can reach near 10000 pcs and big capacity near 2000pcs.

Q 7.Where is your market?

A. Our products are popular in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East,Eastern Asia, Western Europe and so on.Some of them are our regular customers and some of them are developing. We hope you can join us .

Q 8. what kind of certificate you have ?

A. Our company already achieve ISO9001, and for products, we have CE,PCT,SGS.
